Operation
38 Operating Instructions 1767 - 00.0 - 12/2016
4.9.2 Locking the sewing feet at top dead center
There is a lever at the back of the machine for holding the sewing
feet at top dead center.
Fig. 19: Locking the sewing feet at top dead center
CAUTION
Risk of injury from moving parts!
Crushing possible.
Do NOT put your hands underneath the sewing
feet when the lock is being canceled.
(1) - Sewing feet at top dead center (2) - Top dead center removed
