Programming
Operating Instructions 1767 - 00.0 - 12/2016 61
5.2.7 Activating the thread clamp
The thread clamp holds the thread firmly to pull it down and loop
it while sewing on.
To activate the thread clamp:
1. Press.
The LED illuminates.
5.2.8 Setting the needle position after sewing stop
You can determine where the needle is positioned after a sewing
stop.
There are two options:
• Top dead center (needle position 2)
• Bottom dead center (needle position 1)
To activate the top dead center after a sewing stop:
1. Press.
The LED illuminates; i.e., the needle is raised after a sewing
stop.
If the needle is to be in the bottom dead center after a sewing stop,
press again.
5.2.9 Activating sewing foot lift after thread cutter
The sewing foot lift after thread cutter lifts the sewing foot after
the thread is cut.
To activate the sewing foot lift after thread cutter:
1. Press.
The LED illuminates.
