Operation
Operating Instructions 1767 - 00.0 - 12/2016 39
To lock the sewing feet at top dead center:
1. Push the lever on the rear of the machine up or down.
• Locking the sewing feet at top dead center: Push the lever
down (1)
• Canceling the lock of the sewing feet: Push the lever up (2)
You can also use the pedal to cancel the upper position:
1. Press the pedal halfway back.
The lever swivels back up, and the lock is canceled.
4.9.3 Setting the sewing foot pressure
The adjusting wheel at the top left of the machine arm determines
the contact pressure the sewing foot exerts on the sewing material.
The pressure can be adjusted continuously by turning the adjust-
ing wheel.
The correct pressure depends on the sewing material:
• Lower pressure for soft materials, e.g. cloth
• Higher pressure for hard materials, e.g. leather
Proper setting
The sewing material does not slip and is correctly transported.
Disturbance from incorrectly set sewing foot pressure
• Excessively high pressure: Tearing of the sewing material
• Excessively low pressure: Slipping of the sewing material
