Operation
42 Operating Instructions 1767 - 00.0 - 12/2016
To set the height of the sewing foot stroke::
1. Turn the adjusting wheel (1).
• To increase the sewing foot stroke: Turn the adjusting
wheel (1) clockwise
• To reduce the sewing foot stroke: Turn the adjusting
wheel (1) counterclockwise
4.10 Setting the stitch length
Depending on the equipment, the machine has 1 or 2 adjusting
wheels for stitch length.
The stitch length can be adjusted continuously between 0 and 9 mm.
Fig. 22: Setting the stitch length
To set the stitch length:
1. Turn the adjusting wheel (3).
• To increase stitch length: Turn the adjusting wheel
counterclockwise
• To reduce stitch length: Turn the adjusting wheel
clockwise
(1) - Button for the stitch length on
the Push buttons
(2) - Adjusting mark for indicating
the stitch length selected
(3) - Adjusting wheel for the stitch
length
