Operation
Operating Instructions 1767 - 00.0 - 12/2016 37
4.9 Sewing feet
4.9.1 Lifting the sewing feet
The sewing feet are lifted electro-pneumatically using the pedal.
Fig. 18: Lifting the sewing feet
To lift the sewing feet:
1. Press the pedal (1) halfway back.
The machine stops and lifts the sewing feet.
The sewing feet remain up as long as the pedal (1) is
pressed halfway back.
OR
1. Press the pedal (1) fully back.
The thread cutter is activated, and the sewing feet are
raised.
(1) - Pedal
