Operation
46 Operating Instructions 1767 - 00.0 - 12/2016
4.13 Sewing
The pedal starts and controls the sewing process.
Fig. 25: Sewing
Initial position:
• Pedal position 0:
Machine stationary, needles up, sewing feet down.
To position the sewing material:
1. Press the pedal halfway back in pedal position -1.
The sewing feet are lifted.
2. Push the sewing material into the initial position.
WARNING
Risk of injury from sharp parts!
Punctures possible.
Take care not to accidentally press the pedal.
Do NOT reach into the needle tip area.
(1) - Pedal position +1: Sewing active
(2) - Pedal position 0: Rest position
(3) - Pedal position -1:
Lifting the sewing feet
(4) - Pedal position -2: Sew end
bartack and cut off thread
