Technical data
Operating Instructions 1767 - 00.0 - 12/2016 107
11 Technical data
Data and characteristic values
Technical data Unit Class
Machine type 1767
Stitch type Double lockstitch 301
Hook type Vertical hook, XXL
Number of needles 1-2
Needle system 134-35
Needle strength [Nm] 90-180
Thread strength [Nm] 120/3 - 10/3
120/3 - 15/3
Stitch length [mm] 9
Speed maximum
[min
-1
]
3000
Speed on delivery
[min
-1
]
3000
Mains voltage [V] 230
Mains frequency [Hz] 50/60
Operating pressure [bar] 6
Length [mm] 690
Width [mm] 220
Height [mm] 460
Weight [kg] 59
Power input [kVA] 0.75
