Working basis

Service Instructions 878-M PREMIUM - 03.0 - 10/2019 17

3.4.3 Removing and placing the head cover

Fig. 4: Removing and placing the head cover

Removing the head cover

1. Loosen the screws (2).

2. Remove the head cover (1).

Placing the head cover

1. Place the head cover (1).

2. Tighten the screws (2).

3.4.4 Removing and placing the valve cover

Fig. 5: Removing and placing the valve cover

Important

When removing and positioning the valve cover, be sure not to pull off any

cables.

(1) - Head cover (2) - Screws

①

②

(1) - Valve cover (2) - Screws

①

②
