Integrated motor

62 Service Instructions 878-M PREMIUM - 03.0 - 10/2019

Assembling the motor

1. Insert the motor into the toothed belt wheel of the upper shaft.

2. Tighten the 3 screws (2) on the motor flange.

3. Tighten the screws (1).

Important

The first row of the screws (1) on the toothed belt wheel in the direction of

rotation should be tightened up to the surfaces of the shaft.

16.1.4 Assembling the cover

Fig. 53: Assembling the cover

1. Place the cover (2).

2. Tighten the screws (1).

(1) - Screws (2) - Cover
