Programming

84 Service Instructions 878-M PREMIUM - 03.0 - 10/2019

17.6.3 Setting the Input configuration (InputConfig) parameter

Configure and allocate the inputs here. The table shows the inputs and

their allocation.

Machine input signal Input

Buttons on the push buttons

S1 X120T.3

S2 X120T.16

S3 X120T.4

S4 X120T.17

S5 X120T.5

S6 X120T.18

Knee button S1 X120T.15

Knee button S2 X120T.2

Electronic handwheel S1 X100B.15

Operation lock input

(input on the circuit board)

X120B.2

DB3000 IN (X23)

(input on the circuit board)

X120B.15

Light barrier (X21) (optional) X100B.4

Additional button S1 (optional) X120B.16

Additional button S2 (optional) X120B.4
