Programming
86 Service Instructions 878-M PREMIUM - 03.0 - 10/2019
A mode can be allocated for every output (parameter T 56 00). The following
table lists the modes:
17.6.5 Setting the Stitch functions (StitchFunctions) parameter
The machine counts the stitches when a program is processed with the
pedal. If the operator sews half stitches or full stitches manually, they can
also be counted, if required. To do so, this function must be active.
The electronic handwheel is not affected by this setting.
STL (X17) X120B.22
STL(FA) (X18) X120B.23
FL (X15) (X22) X90.12
FF3 OUT (X22) X90.15
Mode Function
0 No function
1 Needle cooling
2 Cleaning signal for the residual thread monitor
3 Pos 1 (needle down)
4 Pos 2 (thread lever up)
5 Motor running signal
6 Feed dog/seam center guide
7 Sewing foot lift signal
8 Puller
9 Pressure for Puller
10 Backtack
11 Backtack Process
12 Thread Trimmer
13 In Seam
Machine output signal Output
