DURKOPP ADLER 878-M PREMIUM - Assembling the Handwheel

130 pages

To Next Page

To Previous Page

Integrated motor

Service Instructions 878-M PREMIUM - 03.0 - 10/2019 63

16.1.5 Assembling the handwheel

Fig. 54: Assembling the handwheel

1. Fit the handwheel (1) and tighten all three screws (2).

(1) - Handwheel (2) - Screws

①

②
