A mode can be allocated for every input (parameter T 53 00).
The following table lists the modes:
17.6.4 Setting the Output configuration (OutputConfig) parameter
Configure and allocate the outputs here. The table shows the outputs and
their allocation. The pins on the circuit board are labeled and must be allo-
cated according to the table, depending on what was connected to the pin.
Menu item Setting options
Mode 0 No function
1 Threading position
2 Bartack active/inactive.
3 Manual bartack
4 Half stitch
5 Full stitch
6 Point position
8 Needle height
11 2. Needle thread tension
12 Change of stitch length
15 Seam center guide/feed dog
18 Light barrier
20 Operation lock when contact is opened normally (NO)
21 Quick stroke height adjustment
23 Change to next seam section
25 2nd position of edge guide
26 Sewing foot lightening
27 2nd fullness degree value
29 Puller
31 Motor blockage inverse
32 Motor blockage in seam
44 Short stitch length
Stored On – stored
OffOff – not stored
Machine output signal Output
ML (X22) X120B.9
NK (X22) X120B.10
RA (X16) X120B.12
