8.2.2.2 Disengaging the articulation lock
WARNING!
Danger of crushing by the articulating
machine!
– Do not step into the articulation area of the
machine while the engine is running.
1. Remove the locking bolt and the articulation lock from the
eyelet and swivel back into place in the holding fixture.
2. Let the locking bolt click into place.
Fig. 126
Maintenance – Preparations/concluding work
