6.6.3 Charging the power pack with the external battery charger
1. Push the lock (1) on the mains unit of the battery charger for-
wards and pull the plug (2) upwards out of the mains unit.
2. Plug the country-specific plug onto the mains unit.
3. Remove the battery from the remote control and insert it in
the charger.
4. Connect the battery charger mains unit to a power source.
Make sure the two light emitting diodes on
the charger and mains unit light up.
ð
The green LED on the charger flashes when the battery
is charged.
Fig. 115
Fig. 116
Fig. 117
Fig. 118
Operation – Remote control battery (radio operation)
D.ONE
94
