4.3 Main battery switch
Position “on” Main battery switch locked
Normal position, operation
Turn anticlockwise Main battery switch can be pulled out
Disconnects the batteries from the on-
board electrics, e.g. to prevent unauthor-
ised use
Individual control units may still be con-
nected to the on-board electrics despite
the main battery switch being pulled out
Fig. 32
Indicators and control elements – Main battery switch
D.ONE
54
