Dynapac D.ONE - Remote Control; Steering Lever

4.4 Remote control
MIN
MAX
AUTOMATIC
321
8
5
10 9
4
6
11
7
B-720-0041
Fig. 33
1 Steering lever
2 Vibration pre-selection toggle switch
3 Toggle switch for travel ranges
4 Engine speed toggle switch
5 Travel lever
6 Start button
7 Starter switch
8 Vibration toggle switch
9 Emergency stop switch
10 Radio operation control light
11 Button for warning horn
4.4.1 Steering lever
Shift to the left Machine steers to the left
Shift to the right Machine steers to the right
MIN
MAX
AUTOMATIC
B-720-0023
Fig. 34
Indicators and control elements – Remote control
D.ONE
55
