8.8.3 Replacing the air filter
Perform this maintenance work at the latest after
one year.
Protective equipment:
n
Working clothes
n
Safety shoes
n
Protective gloves
1.
Park the machine safely
Ä
Chapter 6.5 „Parking the machine
in secured condition“ on page 90.
2. Release the snap bow and take off the cover.
3. Clean the cover and dust discharge valve.
4. Pull out the air filter with a slight turning motion and replace.
5. Thoroughly clean the filter housing and sealing faces.
6. Clean the inside of the drain pipe in the filter housing thor-
oughly.
7. Slide the new air filter carefully into the housing.
NOTICE!
Danger of engine damage!
– The dust discharge valve must point vertically
downwards.
– Make sure that the cover locks engage cor-
rectly.
8. Reinstall the cover.
Fig. 142
Fig. 143
Fig. 144
Maintenance – Every 250 operating hours/annually
D.ONE
118
