Dynapac D.ONE - Input Codes for BLM Control

12.2 Input codes for BLM control
Fault description Cause Remedy
1010 Output valve steering right, Y 237 Display value = output voltage in Volt
Voltage at output Display value = output voltage in Volt
1011 Output valve steering right, Y 237 Display value = output current in Amperè
Current at output Display value = output current in Amperè
1012 Output valve steering right, Y 237 0000 = Output not triggered
0001 = Output triggered
Logic level of control 0000 = Output not triggered
0001 = Output triggered
1015 Valve control, steering 0100 = steering to the left
0010 = Valve not triggered
0011 = steering to the right
0100 = steering to the left
0010 = Valve not triggered
0011 = steering to the right
1020 Output valve steering left, Y 238 Display value = output voltage in Volt
Voltage at output Display value = output voltage in Volt
1021 Output valve steering left, Y 238 Display value = output current in Amperè
Current at output Display value = output current in Amperè
1022 Output valve steering left, Y 238 0000 = Output not triggered
0001 = Output triggered
Logic level of control 0000 = Output not triggered
0001 = Output triggered
1030 Output valve travelling forward, Y 16 Display value = output voltage in Volt
Voltage at output Display value = output voltage in Volt
1031 Output valve travelling forward, Y 16 Display value = output current in Amperè
Current at output Display value = output current in Amperè
1032 Output valve travelling forward, Y 16 0000 = Output not triggered
0001 = Output triggered
Logic level of control 0000 = Output not triggered
0001 = Output triggered
1035 Valve control, travel system 0100 = Driving forward
0010 = Drum stopped
0011 = Driving reverse
Outputs for travel functions
Appendix – Input codes for BLM control
D.ONE
181
