Dynapac D.ONE - Loading the Machine

7.2 Loading the machine
Use only stable loading ramps of sufficient load bearing capacity.
Loading ramps and transport vehicle must be free of grease, oil,
snow and ice.
The ramp inclination must be less than the gradeability of the
machine.
Make sure that any persons keep a safety distance of at least 2
metres while the machine is driven onto or down from the transport
vehicle. The instructing person should not be inside the travel
range of the machine.
Distance from middle of front drum Height
475 mm
18.7 in
512 mm
20.2 in
1. Switch the toggle switch for travel speed ranges to the “rear”
position.
2.
DANGER!
Danger to life caused by the machine slip-
ping or turning over!
– Make sure that no persons are in the
danger zone.
Drive the machine carefully onto the transport vehicle.
3. Observe the centre of gravity.
4. Switch off the engine and remove the ignition key.
5.
Engage the articulation lock Ä Chapter 8.2.2.1 „Engaging the
articulation lock“ on page 103.
Centre-of-gravity position
L
H
B-720-0102
Fig. 119
B-720-0104
Fig. 120
Loading / transporting the machine – Loading the machine
D.ONE
97
