Dynapac D.ONE - List of Fault Codes

12.1 List of fault codes
Fault code Function group
1000 - 1999 Travel system
2000 - 2499 Steering
2500 - 2999 Remote controls
5000 - 5499 Diesel engine
7000 - 7499 Input codes for machine parameterization
7500 - 7999 Operating hour meter, load spectrum (input codes)
8000 - 8999 Severe software error
9000 - 9998 External IO nodes, joysticks, data collectors (CAN communication and hardware defects )
9999 Unknown fault, displayed value higher than +/- 10000, automatic output by the BMFSA
Code Fault reaction Description of fault Possible cause Ter-
minal
on
BLM
Input
code
for
diag-
nose
1030 Output is switched
off, functionno
longer possible
Output valve travelling for-
ward, Y 16
Too high current flow out of
this output Output was
switched off!
Excessive current flow in
current path, probably
because of a defective coil
or a short circuit to ground
X3:22 -
1031 Output is switched
off, function no
longer possible
Output valve travelling for-
ward, Y 16
Short-circuit current flow out
of this output Output was
switched off!
Short circuit to ground in
the current path
Lines rubbed through
Valve defective
X3:22 -
1032 Output is switched
off, function no
longer possible
Output valve travelling for-
ward, Y 16
No or too low current flow out
of this output
Wire breakage in current
path
Current path connected to
+12V
X3:22 1030
1031
1032
1033 Engine is shut
down
Output valve travelling for-
ward, Y 16
Although the output is
switched off, voltage is
present
Current path connected to
+12V
X3:22 1030
1031
1032
Overview
Fault codes of travel functions
Appendix – List of fault codes
D.ONE
170
