6.
WARNING!
Danger of burning on hot components!
– Wear your personal protective equipment
(protective gloves, protective clothing).
– Avoid touching hot components.
Clean and remove the bleed screw (1) and drain plug (2)
from the front drum.
7. Drain off and collect all oil.
8. Lower the machine and attach lifting tackle to the rear lashing
point.
9. Lift the machine at the rear and support the rear drum.
10. Secure the front drum with a wheel chock.
11. Fill the front drum with oil via the drain opening.
12. Screw the bleed screw (1) and drain plug (2) back in tightly.
13.
WARNING!
Danger of burning on hot components!
– Wear your personal protective equipment
(protective gloves, protective clothing).
– Avoid touching hot components.
Clean and remove the bleed screw (1) and drain plug (2)
from the rear drum.
14. Drain off and collect all oil.
15. Lift the machine at the front again, support the front drum
securely, and secure the rear drum with a wheel chock.
B-720-0047
OIL
1
2
Fig. 148
710 mm
28 in
B-720-0046
Fig. 149
B-720-0050
1
2
Fig. 150
B-720-0049
OIL
1
2
Fig. 151
Maintenance – Every 250 operating hours/annually
D.ONE
121
