Chapter 11: Reference Section 229
MIDI SPECIFICATION
Offset Name Range
0 Preset Name 12 chars, ASCII 32-127
12 Preset Low Key 0-127 MIDI key number
13 Preset Hi Key 0-127 MIDI key number
14 Bend Range 0-13, ± 0-12 semitones, 13 = Global
15 Velocity Curve 0-5, 0 = Off, 5 = Global
16 Keyboard Center 0-127 MIDI key number
17 Tune Table 0-5, Equal, Just C, Vallotti,
19-Tone, Gamelan, User
18 Mix Bus 0-3, Main, Sub1, FXA, FXB
19 Port Mode 0-5, Mono, Poly 1-5 keys
20 X-Fade Mode 0-2, Off, XFade, XSwitch
21 X-Fade Direction 0-1, Pri->Sec, Sec->Pri
22 X-Fade Balance 0-127
23 X-Fade Amount 0-255
24 X-Switch Pointt 0-127, MIDI key number or velocity
25 Note-on Source See PATCHCORDS SRC
26 Note-on Dest. See PATCHCORDS SRC
27 Note-on Amount -128 to +127
... 10 note-on cords (3 parms each)
55 Realtime Source See PATCHCORDS DEST
56 Realtime Dest. See PATCHCORDS DEST
57 Realtime Amount -128 to +127
... 10 realtime cords (3 parms each)
85 Foot Dest. See PATCHCORDS DEST
... 3 footswitch cords (1 parm each)
88 Ctrl. A Amount -128 to +127
89 Ctrl B Amount -128 to +127
90 Ctrl C Amount -128 to +127
91 Ctrl D Amount -128 to +127
92 Pressure Amount -128 to +127
93 LFO Shape 0-4, Rand, Tri, Sine, Saw, Square
94 LFO Rate 0-127
95 LFO Delay 0-127
96 LFO Variation 0-127
97 LFO Amount -128 to +127
... 2 LFOs (5 parms each)
103 FG Amount -128 to +127
104 FG Seg Level See FUNCGEN LEVELS
105 FG Seg Time 0-4095 msecs
▼ The parameter numbers
shown at right must be
added to the Preset Param-
eter Base value (8192 for
preset parms) in order to
access individual parameters.
