Chapter 11: Reference Section 233
MIDI SPECIFICATION
• Midimap Data
Version 01 of the midimap follows. If map is sent to current selected
location, the scratch map will be loaded from the newly stored map.
Midimap numbers: 0-15 RAM, 16-31 CARD
F0 SysEx Status Byte
18 E-mu Mfg. ID
0C Morpheus Product ID
dd Device ID 0-15
47 Command ID
vv Data Version
ll Midimap Number ls byte
mm Midimap Number ms byte
Offset Name Range
0 Midimap Name 12 chars, ASCII 32-127
12 Ch. Program See PROGRAM NUMBERS
13 Ch. Bank 0-4, See PROG. NUMBERS for bank #s
14 Ch. Volume 0-127
15 Ch. Pan ± 7, -8 = Preset
16 Ch. Mix Bus -1 = preset, 0-3 Main, Sub1, FxA, FxB
17 Ch. Enable 0-1, Off, On
18 Ch. ProgChg Enbl 0-1, Off, On
19 Ch. BankChg Enbl 0-1, Off, On
20 Ch. VolCtl Enbl 0-1, Off, On
21 Ch. PanCtl Enbl 0-1, Off, On
22 Ch. PWhl Enbl 0-1, Off, On
23 Ch. MPress Enbl 0-1, Off, On
24 Ch. PPress Enbl 0-1, Off, On
25 Ch. Ctl. A Enbl 0-1, Off, On
26 Ch. Ctl. B Enbl 0-1, Off, On
27 Ch. Ctl. C Enbl 0-1, Off, On
28 Ch. Ctl. D Enbl 0-1, Off, On
29 Ch. Ftsw. 1 Enbl 0-1, Off, On
30 Ch. Ftsw. 2 Enbl 0-1, Off, On
31 Ch. Ftsw. 3 Enbl 0-1, Off, On
... for 16 channels (20 parms each)
332 Prog Map -1 for None, 0-3
333 FX A Type See EFFECTS TYPES
334 FX A Parm Vals See EFFECTS TYPES
