Morpheus Operation Manual232
MIDI SPECIFICATION
•••␣ The parameters labeled
with (Z) equate to zone 1.
Zones 2-16 begin at param-
eter number 72.
No. Name Range
0 Hyperpreset Name 12 chars, ASCII 32-127
12 Port Mode 0-5, Mono, Poly 1-5 keys
13 FG Seg Level See FUNCGEN LEVELS
14 FG Seg Time 0-4095 msecs
15 FG Seg Shape See FUNCGEN SHAPES
16 FG Seg CondJump See FUNCGEN CONDITIONS
17 FG Seg CondVal ± 127
18 FG Seg DestSeg 0-7 segment number
... 8 funcgen segments (6 parms each)
61 Z Preset -1 = None, 0-MAX PRESET
62 Z Volume 0-127
63 Z Pan ± 14
64 Z Low Key 0-127 MIDI key number
65 Z High Key 0-127 MIDI key number
66 Z Low Vel 0-127
67 Z High Vel 0-127
68 Z Vel Offset ± 126
69 Z Xpose ± 36 keys
70 Z Coarse Tune ± 36 semitones
71 Z Fine Tune ± 64 semitones/64
Z = zone ... 16 zones (11 parms each)
cs Checksum
F7 End of SysEx Status
• Midimap Request
Request midimap. Request for card midimaps will be ignored if card is
not present. Midimap numbers: 0-15 RAM, 16-31 CARD. Values
0x0400 + bank number (0-1) represent requests for banks. (Banks are
blocks of 16 Midimaps) The scratch map is accessed by requesting
MASTER settings or individual parameter requests.
F0 SysEx Status Byte
18 E-mu Mfg. ID
0C Morpheus Product ID
dd Device ID 0-15
46 Command ID
ml ls byte Midimap Number
mb ms byte Midimap Number
F7 End of SysEx Status
