Chapter 11: Reference Section 249
MIDI SPECIFICATION
Transform Filter Type
0 2 frame filter
1 4 frame “square” filter
2 6 frame “phantom cube” filter
3 8 frame “cube” filter
4 unused
5 4 frame “square” filter, gain reduced
•␣ Effect Types
Use the EFFECT LIST command to get a list of the currently available
EFFECTS and their IDs. The effect type number sent via SysEx are
unique IDs. (they are not the index into the screens). Note that the A
and B effect IDs do not overlap. e.g. the A effect StereoFlange does not
have the same ID as the B effect StereoFlange.
• Parameter Numbers
The following parameter numbers are in decimal.
Parm Parm Range
Number Description
0-128 Proteus Preset Parms
256 Basic Channel 0-15
257 Channel Volume 0-127
258 Channel Pan ± 7, -8 = P
259 Current Program 0-MAXPROGRAM
260 Master Tune ± 64 Semitones
261 Master X-pose ± 12 Midi Keys (semitones)
262 Global Bend 0-12 ± Semitones
263 Global Velcurve 0-8, 0 = Off
264 Midi Mode 0-3, Omni, Poly, Multi, Mono
265 Unused
266 Control A 0-31
267 Control B 0-31
268 Control C 0-31
269 Control D 0-31
270 Footswitch 1 64-79
271 Footswitch 2 64-79
272 Footswitch 3 64-79
273 Midi Modechange Enable0-1, Disabled, Enabled
