USB
One type-A USB port at front panel, support USB 2.0 (480Mbps)
CPLD
CPLDs access by I2C and CPLDs code field upgraded by CPU GPIO
RJ45 LED X’FMR
One RJ45 with LED/one X’FMR embedded
MAC
Broadcom Trident3 BCM56873, 1 pcs, 2000Gbs multi-layer Ethernet switch
controller
NIC
1 x BCM5720
EMP PHY
1 x BCM54616S
Ethernet Ports
48x25G SFP28, 8x100G QSFP28 and 2x10G SFP+ ports
PCB
12-Layers for CPU module
14-Layers for Mainboard
4-Layers for FAN board
4-Layers for Cable board
Power Supply
650W PSU back to front airflow, AC to DC ; front to back airflow, DC to AC, 1+1
redundant load-sharing, hot-swappable
+12V/52.9A output / +5Vsb/4A output
Cooling
6 fan-tray modules with 6 pcs of 40mm x40mm x 56mm 12V fans, hot-swappable
System LED
Driving by CPLD
100G/40G/25G/10G
LED
Driving by MAC LED stream
Push Button
One push button for reset at front panel
Dimension
536 mm (L: Depth) x 438.4mm (W: Width) x 43.5 mm (H: Height)
Mounting Options
Rack Mount
Table 2 Key component Table
Component
Vendor
MFG P/N
Quantity
Remark
CPU Board-CPU
Intel
Broadwell-DE XeonD-1518
1
MAC
Broadcom
BCM56873
1
NIC
Broadcom
BCM5720
1
EMP PHY
Broadcom
BCM54616S
1
CPLD
Altera
5M1270ZF256C5N
1
For CPU system
CPLD
Altera
5M1270ZF256C5N
2
For Main board System
and QSFP28 LED
CPLD
Altera
5M2210ZF324C5N
1
For SFP28 LED
CPLD
Altera
5M1270ZF256C5N
1
For Fan board System
I2C Switch
NXP
PCA9548APW
10
