Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
92
P14
INT_MGMT_PHY_N
IN
R3
SFP+_MOD_ABS_P41
IN
R9
SFP+_DIS_P35
OUT
T2
SFP+_DIS_P37
OUT
T6
SFP+_RXLOS_P38
IN
5.12.2. CPLD 1 Register
Table 31 CPLD1 Register Table
Address
Register
R/W
Default value
0x00
Board Info
Read Only
0x0E
0x01
PCB version
Read Only
0x00
0x02
Power module status-1
Read Only
0x3C
0x03
Power module status-2
Read& Write
0x0C
0x04
System Reset-1
Read& Write
0xFF
0x05
System Reset-2
Read& Write
0x07
0x06
System Reset-3
Read& Write
0xFF
0x07
System Reset-4
Read& Write
0xFF
0x08
System Reset-5
Read Only
0x0F
0x09
System Reset-6
Read& Write
0x00
0x0A
Interrupt Status-1
Read Only
0xFF
0x0B
Interrupt Status-2
Read Only
0xFF
0x0C
Interrupt Status-3
Read Only
0x03
0x0D
Interrupt Status-4
Read& Write
0x00
0x0E
Interrupt Status-5
Read& Write
0x00
0x0F
Interrupt Status-6
Read& Write
0x00
0x10
Module Present -1
Read Only
0xFF
0x11
Module Present -2
Read Only
0xFF
0x12
Module Present -3
Read Only
0x0F
0x13
Module Present -4
Read Only
0xFF
0x14
Module Disable-1
Read& Write
0x00
0x15
Module Disable-2
Read& Write
0x00
0x16
Module Disable-3
Read& Write
0x00
0x17
Module RX_LOSS-1
Read Only
0xFF
0x18
Module RX_LOSS-2
Read Only
0xFF
0x19
Module RX_LOSS-3
Read Only
0x0F
