Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
91
C12
PS2_AC_ALERT
IN
M3
P51_MODPRSNT_N
IN
H13
PS1_EEPROM_WP
OUT
Reserved
C2
SFP+_FLT_P48
IN
D2
SFP+_RXLOS_P47
IN
D3
LM75BD_SCLK
OUT
N5
P53_INT
IN
N12
TX_DIS_FX1
OUT
N11
RX_LOSS_FX0
IN
F16
CPU_PROCHOT
IN
N6
P56_INT
IN
N7
P55_RESET_N
OUT
L10
SFP+_RXLOS_P40
IN
J3
P50_RESET_N
OUT
C11
PS2_PRESENT
IN
C10
IDT8V89307_INT_REQ
IN
J4
P49_RESET_N
OUT
N13
USB_PWRON_N
OUT
F7
IP_CPLD_BS0_TC
IN
Reserved
G11
Fan_idle
OUT
Reserved
G6
L1_RCVRD_CLK_VALID_BKUP
IN
L7
SFP+_DIS_P41
OUT
N10
PRESENT_FX1
IN
N9
TX_DIS_FX0
OUT
P12
USB_RESET_N
OUT
P13
USB_PWRFLT_N
IN
K6
SFP+_FLT_P42
IN
M4
P52_RESET_N
OUT
F10
FAN_SDA_1
IN/OUT
K11
FAN_SCL_1
OUT
L13
PS1_12V_PG
IN
L14
SFP+_DIS_P34
OUT
M13
SFP+_DIS_P30
OUT
M14
SFP+_FLT_P30
IN
N14
MGMT_PHY_RST_N
OUT
