Edge-Core AS7326-56X - FrontRear Placement; Sub-System of CPU Board

EDGECORE NETWORKS CORPORATION 2018
18
CPLD
CPLD_BDX_CPU_RSMRST
CPLD_CPU_PCH_PLTRST_N
PCH_PLTRST_N
PCH_RSMRST_N
PCH_SYSRESET_N
RESET_CPU_N
PLTRST_N
BDXDE
RSMRST_N
RSMRST_CPU_N
RTCRST_N
Level
shift
Manu_RST
TMP
SYS_RESET_N
RESET_SYS_CPLD
I210 U6
DDR4-
sodimm
DDR_RESET_N
PE_RST_N
PSHBTN_SYS_RESET_N
Level
shift
SYS_PWRBTN_N
PSHBTN_SYS_RESET_N
PWRBTN_N
PCH_PWRBTN_N
BTB 120pin
P1014_RST
PCIE_RST_N
BMM
PWR_BTN_OUT_BMC_N
RST_BTN_OUT_BMC_N
PCA9548
PCA9548_RST_N
2.3. Front/Rear Placement
Figure 9 System Front/Rear Placement
3. Sub-system of CPU Board
The MAC sub-system is used for CPU board to connect the management PHY (BCM54616S) on the
main board, the MAC solution is Broadcom BCM56873.
The BMC5720 communicates CPU via PCIE GEN2 x2, and connect to the management port PHY
BCM54616S on the main board via SGMII / SERDES.
The NCSI interface is used to connect the BMC module to support share NIC function.
