Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
116
V17
N/A
V2
P10_Lane1_LED_G
OUT
V4
P10_Lane1_LED_R
OUT
V5
P11_Lane2_LED_B
OUT
V6
P11_Lane2_LED_R
OUT
V8
N/A
V9
N/A
N9
SFP+_FLT_P13
IN
N10
SFP+_DIS_P13
OUT
J6
CPLD2_25MHz
IN
K6
N/A
K13
N/A
J13
SFP+_FLT_P21
IN
5.12.4. CPLD 2 Register
Table 33 CPLD2 Register Table
Address
Register
R/W
Default value
0x01
CPLD version
Read Only
0x02
0x02
CPLD2 interrupt
Read &Write
0x01
0x03
Module Fault-1
Read Only
0xff
0x04
Module Fault-2
Read Only
0xff
0x05
Module Fault-3
Read Only
0xff
0x06
Module Fault-4
Read Only
0xff
0x07
Module Disable-1
Read &Write
0x00
0x08
Module Disable-2
Read &Write
0x00
0x09
Module Disable-3
Read &Write
0x00
0x0A
Module Disable-4
Read &Write
0x00
0x0B
Module RX_LOSS-1
Read Only
0xff
0x0C
Module RX_LOSS-2
Read Only
0xff
0x0D
Module RX_LOSS-3
Read Only
0xff
0x0E
Module RX_LOSS-4
Read Only
0xff
0x0F
Module Present-1
Read Only
0xff
0x10
Module Present-2
Read Only
0xff
0x11
Module Present-3
Read Only
0xff
0x12
Module Present-4
Read Only
0xff
0x20
SFP28 RGB LED -1
Read &Write
0x07
