Edge-Core AS7326-56X - Page 115

EDGECORE NETWORKS CORPORATION 2018
115
R7
SFP+_MOD_ABS_P17
IN
R8
SFP+_DIS_P17
OUT
R9
SFP+_MOD_ABS_P9
IN
T10
N/A
T11
N/A
T12
N/A
T13
N/A
T14
N/A
T15
N/A
T4
SFP+_RXLOS_P12
IN
T5
SFP+_RXLOS_P6
IN
T6
SFP+_DIS_P6
OUT
T7
SFP+_MOD_ABS_P6
IN
T8
SFP+_RXLOS_P5
IN
T9
SFP+_DIS_P12
OUT
U1
P10_Lane1_LED_B
OUT
U10
P14_Lane1_LED_R
OUT
U11
P14_Lane1_LED_B
OUT
U12
SFP+_MOD_ABS_P10
IN
U13
I2C_0_SCL_CPLD2
IN
U14
SFP+_RXLOS_P14
IN
U15
SFP+_DIS_P15
OUT
U16
SFP+_RXLOS_P11
IN
U18
P16_Lane3_LED_G
OUT
U3
P9_Lane0_LED_B
OUT
U4
P9_Lane0_LED_G
OUT
U5
P9_Lane0_LED_R
OUT
U6
P11_Lane2_LED_G
OUT
U7
SFP+_FLT_P6
IN
U8
SFP+_MOD_ABS_P5
IN
U9
SFP+_FLT_P12
IN
V10
P14_Lane1_LED_G
OUT
V11
P15_Lane2_LED_B
OUT
V12
P15_Lane2_LED_G
OUT
V13
P15_Lane2_LED_R
OUT
V14
P16_Lane3_LED_B
OUT
V15
P16_Lane3_LED_R
OUT
