M18
P13_Lane0_LED_G
OUT
N13
SFP+_MOD_ABS_P13
IN
N14
SFP+_MOD_ABS_P24
IN
N15
SFP+_MOD_ABS_P11
IN
N16
SFP+_RXLOS_P16
IN
N17
P13_Lane0_LED_R
OUT
N18
P13_Lane0_LED_B
OUT
P14
SFP+_FLT_P15
IN
P15
SFP+_FLT_P11
IN
P16
P19_Lane2_LED_R
OUT
P17
P20_Lane3_LED_G
OUT
P18
P20_Lane3_LED_R
OUT
R15
SFP+_DIS_P11
OUT
R16
SFP+_RXLOS_P31
IN
R17
SFP+_DIS_P26
OUT
R18
SFP+_FLT_P26
IN
T16
I2C_0_SDA_CPLD2
IN/OUT
T17
SFP+_MOD_ABS_P27
IN
N11
SFP+_RXLOS_P13
IN
N12
SFP+_DIS_P19
OUT
N7
IP_LED_CLK3
IN
N8
IP_LED_DATA3
IN
P10
SFP+_DIS_P10
OUT
P11
SFP+_FLT_P10
IN
P12
SFP+_FLT_P19
IN
P13
SFP+_MOD_ABS_P14
IN
P6
SFP+_DIS_P24
OUT
P7
CPLD_RST
IN
P8
CPLD2_INT
OUT
P9
SFP+_RXLOS_P24
IN
R10
SFP+_RXLOS_P9
IN
R11
SFP+_RXLOS_P10
IN
R12
SFP+_DIS_P9
OUT
R13
SFP+_FLT_P9
IN
R14
N/A
R5
SFP+_DIS_P5
OUT
R6
SFP+_FLT_P5
IN
