Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
67
100G
10
10
40G
10
00
10G
00
00
1G
00
11
4 x 25G
00
10
4 x 10G
00
00
2 x 50G
01
10
Link-up/ Activity
LED
1
ON
0
OFF
Toggle
Activity
Type
LED bit stream(b0 … b13)
SFP+
QSFP
OFF
00-000-000-000-000
off
off
1G
00-111-111-111-111
N/A(off)
N/A (off)
10G
00-001-001-001-001
Amber/Yellow
Purple
25G
00-101-101-101-101
Green
Amber/Yellow
40G
10-001-001-001-001
N/A(off)
Blue
100G
10-101-101-101-101
N/A(off)
Green
xxG
xx-xxx-xxx-xxx-xxx
N/A(off)
Green
If the lane[1:0] is “10”, the link-up/ activity bit of first lane will be active and other lanes will be
inactive. If the lane[1:0] is “01”, the link-up/ activity bit of first and three lane will be active and
other lanes will be inactive. If the lane[1:0] is ‘00”, the link-up/ activity bit of all lanes will be active.
4.6. QSFP28
The system has 8x QSFP28 ports can support 100Gbps(4x25Gbps or 2x50Gbps Fanout)/
40Gbps(4x10Gbps Fanout). The QSFP28 port support optical transceiver and DAC. The power class
can support up to 5W.
4.7. SFP28
The system has 48 x SFP28 ports can support 25Gbps/10Gbps/1Gbps. The SFP28 port support
optical transceiver and DAC. The power class can support up to 2W.
4.8. SFP+
The system has 2 x SFP+ OOB ports can support 10Gbps/1Gbps. The SFP+ port support optical
transceiver and DAC. The power class can support up to 1.5W.

Edge-Core AS7326-56X Specifications

General

Brand	Edge-Core
Model	AS7326-56X
Category	Switch
Language	English
