5. Sub-system
5.1. Management PHY (BCM54616S)
The management port support 10/ 100/ 1000M Ethernet speed.
5.2. Configurations of MGMT PHY (BCM54616S)
Table 20 MGMT PHY Configurations Table
Pin Number
Pin Name
Function Description
G7
G6
H6
G10
LED1
LED2
LED3
LED4
LED1 High >> Copper AN enable
LED2 High >> Full-duplex
LED3 High >>
LED4 High >> AN at 10/100/1000BASE-T
A8
B7
INTERF_SEL0
INTERF_SEL1
INTERF_SEL[1:0]
00 = RGMII-Copper (Copper mode)
01 = RGMII-Fiber (Fiber mode)
*10 = SGMII-Copper (SGMII mode)
11 = Serdes-Copper (Media Converter mode)
H10
J0
J9
K10
K9
PHY_ADDR_0
PHY_ADDR_1
PHY_ADDR_2
PHY_ADDR_3
PHY_ADDR_4
ADDR = 111111
5.3. POR of MGMT PHY (BCM54616S)
The detailed power-on reset (POR) flow is as follows:
1. 3.3V up and Ref clock up
2. 3.3V enable MPS1484 to generate 2.5V
3. All powers are stable, POWR607 inform CPLD
4. CPLD receive the signal, CPLD assert Reset_N high
5.4. I2C
The CPU board has three I2C channels for our application. The Channel 1 used for Power
Supply, Clock GEN, DC/DC, thermal sensor, CPLD2 and Fan CPLD. The channel 2 used for Power
Supply, CPLD 1,3, USB HUB, DC/DC, Multiplexer, Retimer, port 49~56 QSFP28 and port 57~58 SFP+.
The channel 2 used for port 1~48 SFP28.
