Page #168 background image
EDGECORE NETWORKS CORPORATION 2018
168
Net name
pin number
Note
FAN_PWM_6
M13
FAN6
FAN_PWM_5
M14
FAN5
FAN_LED_R_4
M16
FAN2 LED
FAN6_DIR
N13
FAN6
FAN5R_SENSOR
P14
FAN5
FAN2_PRES
C2
FAN2
FAN3_PRES
C3
FAN3
FAN1_PRES
D2
FAN1
FAN1_VENDORID_0
D3
FAN1
FAN1_VENDORID_1
E1
FAN1
FAN1_VENDORID_2
E2
FAN1
FAN2_VENDORID_0
E3
FAN2
FAN2_VENDORID_1
E4
FAN2
FAN2_VENDORID_2
E5
FAN2
FAN3_VENDORID_0
F1
FAN3
FAN3_VENDORID_1
F2
FAN3
FAN3_VENDORID_2
F3
FAN3
FAN4_VENDORID_0
F4
FAN4
FAN4_VENDORID_1
F5
FAN4
FAN4_VENDORID_2
F6
FAN4
FAN5_VENDORID_0
G1
FAN5
FAN5_VENDORID_1
G2
FAN5
FAN5_VENDORID_2
G3
FAN5
FAN6_VENDORID_0
G4
FAN6
FAN6_VENDORID_1
G6
FAN6
FAN6_VENDORID_2
H1
FAN6
FAN_SDA_1_R
M1
FAN_SCL_1
N1
5.12.8. Fan board Register
Table 37 Fan board CPLD Register Table
Address
Register
R/W
Default value
0x00
Board Info
Read Only
0x83
0x01
CPLD version
Read Only
0xC1
