31
RSVD12_AJ67
This pin should have a 5.1K ohm pull down to
GND.
0
RSVD11_AG67
This pin should have a 5.1K ohm pull down to
GND.
0
RSVD10_AN78
This pin should have a 5.1K ohm pull down to
GND.
0
RSVD09_AC64
This pin should have a 5.1K ohm pull down to
GND.
0
SERIRQ_DIR
Recommend 5.1k ohm pull up to VCCIOIN.
1
UART_TXD[0]
Recommend 5.1k ohm pull down to GND.
0
UART_TXD[1]
Controls the security attributes on the NVM - for
pre-production usage only.
0 = Disable NVM Security (Default)
1 = Security Enabled
Recommend 5.1K ohm pull down to GND.
0
LAN_NCSI_RXD0
Recommend 5.1K ohm pull up to VCCIOIN.
1
LAN_NCSI_RXD1
Enable/Disable manageability traffic:
0 = LAN available in S5 for WoL (Default)
1 = LAN not available in S5. Manageability is
disabled.
Recommend 5.1K ohm pull down to GND.
0
LAN_NCSI_ARB_OUT
Selects SVID VR Operating Mode
1 - VCCSCSUS, P1V05_PCH, VCCGBE, VCCIOIN are
combined into one SVID controlled supply.
0 - Separate SVID controllers (default).
1
RSVD84
49.9Ω 1% to GND
0
RSVD93
1k - 5.1kΩ to GND
0
RSVD94
1k - 5.1kΩ to GND
0
RSVD00
1k - 5.1kΩ to VCC3_3
1
RSVD18
1k - 5.1kΩ to GND
0
RSVD16
1k - 5.1kΩ to GND
0
RSVD17
1k - 5.1kΩ to GND
0
RSVD21
1k - 5.1kΩ to GND
0
NCTF/TP
1k - 5.1kΩ to VCC3_3
1
3.4. Memory Mapping
Broadwell-DE SoC contains registers that are located in the processor I/O space and memory space and
sets of PCI configuration registers that are located in PCI configuration space. This chapter describes
Broadwell-DE SoC I/O and memory maps at the register-set level. Register access is also described.
Table 5 PCI devices and functions
Bus:Device:Function
Function Description
Bus0:Device31:Function0
LPC controller
Bus0:Device31:Function2
SATA controller #1
Bus0:Device31:Function3
SMBus controller
Bus0:Device31:Function5
SATA controller#2
