EDGECORE NETWORKS CORPORATION 2018
24
mode to connect BCM54616S in order to support PXE boot function.
Figure 13 Management port function
3.3. Software Configurations of CPU
Figure 14 GPIO
USB1_VBUS
CPU_THERMALTRIP
USB1_PWRFAULT
SYS_CPLD_INT_CPU
CPU_TCK
CPU_TDO
CPU_JTAG_RST
CPU_TMS
MAC_INT_L
CPU_TDI
CPU_PROCHOT
1PPS_CPU
CPLD23_INT_CPU
BDXDE
CPLD
buffer
GPIO14
GPIO18
GPIO9
GPIO10
TDI
Level
shift
GPIO25
THERMTRIP
PROCHOT_N
GPIO26
120pins BTB
connector
SMB
BDX_CPLD_JTAG_TDO
LM75
INT
GPIO44
GPIO45
GPIO46
GPIO24
GPIO59
IP_UART0_SIN
IP_UART0_SOUT
GPIO30
GPIO29
CPLD
