Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
58
GPIO46
1
0
CPU_JTAG_RST(no use)
GPIO48
1
0
SDATAOUT1
GPIO49
1
0
FM_CPU_PROCHOT_PCH_N/
FM_PROCHOT_N
GPIO50
X
X
NC
GPIO51
1
1
4.7k pull to 3.3V
GPIO52
1
1
CPU_SV
GPIO53
1
1
1k pull to gnd
GPIO54
X
X
NC
GPIO55
1
1
FM_BIOS_RCRV_BOOT_N
GPIO57
1
1
FM_ME_RCRV_N
GPIO58
0
X
SML1_CLK
GPIO59
1
BI
XDP_NOA0_PCH
GPIO60
0
X
SML0ALERT#
GPIO61
X
X
NC
GPIO62
0
X
SUSCLK_33K
GPIO65
0
X
NC
GPIO67
0
X
NC
GPIO68
1
1
CPLD interrupt
GPIO69
0
X
NC
GPIO70
0
X
NC
GPIO71
0
X
NC
GPIO72
1
1
1K pull to 3.3V
GPIO74
0
X
SML1ALERT#/TEMP_ALERT#.
GPIO75
0
X
SML1DATA
4. Sub-system of MAC (BCM56873)
The BCM56873 incorporates 20 FalconCore, where 12 FalconCore can operate at 25Gbps and 8
FalconCore can operate at 40G/ 100Gbps.The PCIe interfaces the high bandwidth to transfer any
packet to or from CPU. The PCI interface is configured at PCIe Gen2. It is to directly connect to CPU,
and the bandwidth can be reached PCI2 Gen2 4 lanes.
