Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
57
GPIO18
1
0
XDP_NOA14_PCH/
BDX_CPLD_JTAG_TMS
GPIO19
1
BI-DIR
XDP_NOA9_PCH
GPIO20
1
0
FM_SMI_ACTIVE_PCH_N/
FM_SMI_ACTIVE_CPLD_N
GPIO21
1
BI-DIR
XDP_NOA8_PCH
GPIO22
1
0
SCLOCK
GPIO23
0
X
NC
GPIO24
0
0
NC
GPIO25
1
1
1PPS_CPU (no use)
GPIO26
1
1
SYS_CPLD_INT_CPU
GPIO27
1
1
SOC_FPGA_DIN
GPIO28
1
0
SOC_FPGA_DOUT
GPIO29
1
0
IP_UART0_SOUT(no use)
GPIO30
1
1
IP_UART0_SIN(no use)
GPIO31
1
1
SMB_PWR_ALERT
GPIO32
X
X
NC
GPIO33
X
X
NC
GPIO35
1
0
FM_NMI_EVENT_PCH_N/
FM_NMI_EVENT_CPLD_N
GPIO36
1
0
ADR_STATUS_RD
GPIO37
1
1
ADR_STATUS_CLR
GPIO38
0
0
SLOAD
GPIO39
0
0
SDATAOUT0
GPIO40
0
BI
XDP_NOA1_PCH
GPIO41
1
0
XDP_NOA2_PCH/
CPLD_CONFIG_CLK
GPIO42
1
BI
XDP_NOA3_PCH/
CPLD_CONFIG_DATA
GPIO43
1
0
XDP_NOA4_PCH / ADR_MCU_INIT
GPIO44
0
1
NC
GPIO45
1
1
CPLD23_INT_CPU
