EDGECORE NETWORKS CORPORATION 2018
78
Yellow
Flashing indicates activity.
OFF
There is no link on the port.
Figure 42 SFP+ Port LED
Table 26 SFP+ Port LED Definition
LED
Color
Mode
SFP+ Port LED
On/Flashing
Green
SFP+ port has a valid link at 10G.
Flashing indicates activity.
On/Flashing
Yellow
SFP+ port has a valid link at 1G.
Flashing indicates activity.
OFF
There is no link on the port.
5.9.3. Management Port LED
The management port support 1G/ 100M / 10M speed. Two port LEDs are reserved and
integrated into the RJ-45, yellow at the left side and green at the right side.
Figure 43 Management Port LED
