Edge-Core AS7326-56X - Page 113

EDGECORE NETWORKS CORPORATION 2018
113
F17
SFP+_DIS_P32
OUT
F18
P17_Lane0_LED_B
OUT
G12
SFP+_MOD_ABS_P26
IN
G13
N/A
G14
SFP+_MOD_ABS_P22
IN
G15
SFP+_RXLOS_P19
IN
G16
SFP+_DIS_P20
OUT
G17
SFP+_FLT_P32
IN
G18
SFP+_MOD_ABS_P31
IN
H13
SFP+_DIS_P21
OUT
H14
P18_Lane1_LED_B
OUT
H15
SFP+_MOD_ABS_P19
IN
H16
N/A
H17
N/A
H18
N/A
J14
P35_Lane2_LED_B
OUT
J15
N/A
J16
N/A
J17
N/A
J18
N/A
K14
SFP+_DIS_P14
OUT
K15
SFP+_MOD_ABS_P15
IN
K16
SFP+_FLT_P14
IN
K17
N/A
K18
P35_Lane2_LED_G
OUT
L13
SFP+_MOD_ABS_P18
IN
L14
SFP+_RXLOS_P18
IN
L15
SFP+_FLT_P16
IN
L16
SFP+_RXLOS_P15
IN
L17
P37_Lane0_LED_B
OUT
L18
P37_Lane0_LED_G
OUT
M12
SFP+_DIS_P22
OUT
M13
SFP+_RXLOS_P17
IN
M14
SFP+_FLT_P17
IN
M15
SFP+_MOD_ABS_P16
IN
M16
SFP+_DIS_P16
OUT
M17
P37_Lane0_LED_R
OUT
