Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
90
F5
L1_RCVRD_CLK_VALID
IN
J2
SFP+_RXLOS_P44
IN
K4
P52_INT
IN
M2
SFP+_RXLOS_P45
IN
E13
PS2_AC-OK
IN
Reserved
A4
DIAG_B
OUT
L5
SFP+_MOD_ABS_P42
IN
C13
PS2_PDB_ALERT
OUT
C4
BU_SEL_1
OUT
C5
LOC_R
OUT
C6
System_B
OUT
Reserved
H4
P50_INT
IN
L11
RS232_UART_RX
IN
C15
UCD9090_ALERT_L
IN
Reserved
B16
I2C_0_SCL_CPLD1
IN
F13
PS2_ON
OUT
K3
P51_INT
IN
J16
PCB_Version1
IN
K15
LM75BD1_INT
IN
P7
P56_MODPRSNT_N
IN
P5
P54_RESET_N
OUT
P2
SFP+_RXLOS_P37
IN
P9
P55_INT
IN
P6
P53_MODPRSNT_N
IN
P4
P54_INT
IN
N3
P51_RESET_N
OUT
P8
P56_RESET_N
OUT
D12
LM75BD_SDA
IN/OUT
D4
DIAG_R
OUT
D5
System_R
OUT
Reserved
D6
System_G
OUT
Reserved
D7
LOC_G
OUT
D8
LM75BD2_INT
IN
L3
P49_INT
IN
H15
PS1_AC_ALERT
IN
