Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
89
B12
PCA9548_01_RESET_N
OUT
A13
N/A(CPLD_IP_BS0)
OUT
B8
PCA9548_15_RESET_N
OUT
E8
SFP+_FLT_P41
IN
E7
PCA9548_16_RESET_N
OUT
E5
LM75BD0_INT
IN
A7
PSU2_G
OUT
D9
IDT8V89307_RST
OUT
R4
SFP+_RXLOS_P41
IN
B4
DIAG_G
OUT
B3
FAN_R
OUT
A2
Reset_button_RST
IN
H3
SFP+_FLT_P46
IN
F6
IP_CPLD_BS0_HB
IN
Reserved
T13
SFP+_MOD_ABS_P34
IN
B7
PSU2_B
OUT
A6
PSU2_R
OUT
B1
SFP+_MOD_ABS_P47
IN
L2
SFP+_RXLOS_P43
IN
M1
SFP+_MOD_ABS_P45
IN
L1
SFP+_FLT_P44
IN
J15
SFP+_MOD_ABS_P36
IN
K5
SFP+_RXLOS_P42
IN
K2
SFP+_DIS_P43
OUT
C7
LOC_B
OUT
M7
SFP+_DIS_P39
OUT
R13
SFP+_FLT_P33
IN
M6
SFP+_FLT_P40
IN
R12
SFP+_RXLOS_P34
IN
T8
SFP+_DIS_P33
OUT
R14
SFP+_RXLOS_P29
IN
N1
SFP+_DIS_P44
OUT
K1
SFP+_MOD_ABS_P43
IN
T12
SFP+_MOD_ABS_P35
IN
R11
SFP+_RXLOS_P35
IN
