Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
88
F3
SFP+_DIS_P48
OUT
T9
SFP+_FLT_P35
IN
R5
SFP+_FLT_P39
IN
D13
PS1_PRESENT
IN
R7
SFP+_RXLOS_P39
IN
G3
SFP+_MOD_ABS_P46
IN
G4
SFP+_DIS_P46
OUT
A5
PSU1_G
OUT
F4
SFP+_RXLOS_P46
IN
B5
PSU1_R
OUT
B6
PSU1_B
OUT
R8
SFP+_DIS_P38
OUT
E11
1PPS_GPIO2
OUT
M11
SFP+_FLT_P36
IN
J12
USB_UART_SUSPEND_L
IN
Reserved
E10
PCIE_WAKE_L
IN
Reserved
K13
PS1_ON
OUT
E9
PCIE_INTR_L
IN
E6
PCA9548_02_RESET_N
OUT
A9
PCA9548_12_RESET_N
OUT
F1
SFP+_RXLOS_P48
IN
G2
SFP+_MOD_ABS_P48
IN
A11
IP_BS0_CLK_2
IN
Reserved
E12
CPLD_USB_VBUS_DET
IN
B10
PCA9548_00_RESET_N
OUT
M10
SFP+_MOD_ABS_P40
IN
H1
SFP+_FLT_P45
IN
J1
SFP+_FLT_P43
IN
A15
CPLD23_INT_CPU
OUT
H2
SFP+_MOD_ABS_P44
IN
G1
SFP+_DIS_P45
OUT
B14
MAC_INT_L
IN
Reserved
A10
PCA9548_10_RESET_N
OUT
B9
PCA9548_11_RESET_N
OUT
A8
CPLD_RST
OUT
