EDGECORE NETWORKS CORPORATION 2018
93
0x1A
Module Fault-1
Read Only
0xFF
0x1B
Module Fault-2
Read Only
0xFF
0x1C
Module Fault-3
Read Only
0x0F
0x20
Recovery_CLKvalid&1PPS Mask
Read& Write
0x0F
0x21
System LED -1
Read& Write
0x45
0x22
System LED -2
Read& Write
0x45
0x23
System LED -3
Read& Write
0x45
0x24
System LED -4
Read& Write
0x07
0x25
System LED -5
Read& Write
0x07
0x26
System LED -6
Read& Write
0x07
0x27
USB
Read& Write
0x0F
0x28
MISC-1
Read& Write
0x07
0x29
MISC-2
Read& Write
0x7F
5.12.2.1. Offset 0x00 Board Info (Read Only)
Bit
Name
R/W
Reset Value
Description
7:4
Reserved
NA
NA
3:2
PCB_ID[1:0]
R
11
00 for
01 for
10 for
11 for AS7326-56X
1:0
PCB_version[1:0]
R
11
00 for R0A
01 for R0B
10 for R0C
11 for R01
5.12.2.2. Offset 0x01 CPLD version (Read Only)
Bit
Name
R/W
Reset Value
Description
7:0
CPLD_ver[7:0]
R
0x01
CPLD version
5.12.2.3. Offset 0x02 Power module status-1 (Read Only)
Bit
Name
R/W
Reset Value
Description
7:6
Reserved
NA
NA
5:4
PS[1:2]_AC_ALERT
R
11
0: PSU AC POWER Fail
1: PSU AC POWER Good
3:2
PS[1:2]_12V_PG
R
11
0: PSU 12V Power Fail
1: PSU 12V Power Good
1:0
PS[1:2]_PRESENT
R
00
0: PSU Present
1: PSU Not Present
5.12.2.4. Offset 0x03 Power module status-2 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:4
Reserved
NA
NA
3:2
PS[1:2]_PBD_ALERT
R/W
11
0: PSU Full fan speed
1: PSU Normal fan speed (Default)
