Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
142
D16
N/A
A15
N/A
M3
P51_Lane3_LED_R
OUT
N2
P51_Lane2_LED_R
OUT
E9
P56_Lane1_LED_G
OUT
C13
N/A
B12
P49_Lane2_LED_G
OUT
A12
P50_Lane2_LED_B
OUT
B11
P49_Lane2_LED_B
OUT
C12
N/A
D14
N/A
F12
P48_Lane3_LED_R
OUT
C14
N/A
D15
N/A
B14
N/A
M10
SFP_FX1_LED_R
OUT
G12
IP_LED_CLK4
IN
B13
N/A
A10
P49_Lane1_LED_R
OUT
E12
P47_Lane2_LED_B
OUT
A11
P49_Lane2_LED_R
OUT
B9
P50_Lane1_LED_R
OUT
A9
P49_Lane1_LED_G
OUT
D4
P38_Lane1_LED_G
OUT
D10
P44_Lane3_LED_R
OUT
D13
N/A
C10
P48_Lane3_LED_B
OUT
E5
IP_LED_CLK2
IN
E4
IP_LED_CLK0
IN
E7
IP_LED_CLK1
IN
A7
P50_Lane1_LED_G
OUT
F11
CPLD_RST
IN
F4
P54_Lane1_LED_B
OUT
B3
P34_Lane1_LED_G
OUT
B10
P49_Lane1_LED_B
OUT
D5
P34_Lane1_LED_B
OUT
D8
P45_Lane0_LED_G
OUT
