Light: P3V3 power fail
OFF: P3V3 power ok
LED2
P1V7 (VCCSCFUSESUS) power LED
Color: Red
Light: P1V7 power fail
OFF: P1V7 power ok
LED3
P1V3 (VCCKRHV) power LED
Color: Red
Light: P1V3 power fail
OFF: P1V3 power ok
LED4
P1V05 power LED
Color: Red
Light: P1V05 power fail
OFF: P1V05 power ok
LED5
P2V5(DDR4_VPP) power LED
Color: Red
Light: P2V5 power fail
OFF: P2V5 power ok
LED6
P1V2 (DDR4_VDDQ) power LED
Color: Red
Light: P1V2 power fail
OFF: P1V2 power ok
LED7
P0V6 (DDR4_VTT) power LED, red
Color: Red
Light: P0V6 power fail
OFF: P0V6 power ok
LED8
P1V5 (P1V5_PCH) power LED
Color: Red
Light: P1V5 power fail
OFF: P1V5 power ok
LED9
P1V8 (VCCIN) power LED
Color: Red
Light: P1V8 power fail
OFF: P1V8 power ok
LED10
P5V power LED
Color: Red
Light: P5V0 power fail
OFF: P5V0 power ok
LED11
System LED
Color: Green
Light: System ok
OFF: System fail
LED13
mSATA LED
Color: Green
Bright: SATA DATA transmission
OFF: no mSATA data transmission
LED14
M.2 LED
