Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
70
LM75BD_CPU
4B
switch_CH7
IR3595A
0x10
I2C 0
I2C switch (71)
switch_CH0
PSU1
SMBUS:0x59
EEPROM:0x51
switch_CH1
CPLD1
0x60
switch_CH2
CPLD3
0x64
switch_CH3
IR3595B
0x12
switch_CH4
P1014
0x25
switch_CH5
SFP+
MUX
SFP+:0x50
MUX:0x58
switch_CH6
SFP+
Retimer
SFP+:0x51
Retimer:0x18
switch_CH7
I2C switch (72)
0x72
I2C 0
I2C switch (72)
switch_CH0
QSFP28 PORT 49
0x50, 0x51
switch_CH1
QSFP28 PORT 50
0x50, 0x51
switch_CH2
QSFP28 PORT 51
0x50, 0x51
switch_CH3
QSFP28 PORT 52
0x50, 0x51
switch_CH4
QSFP28 PORT 53
0x50, 0x51
switch_CH5
QSFP28 PORT 54
0x50, 0x51
switch_CH6
QSFP28 PORT 55
0x50, 0x51
switch_CH7
QSFP28 PORT 56
0x50, 0x51
I2C 1
I2C switch (70)
switch_CH0
I2C switch (71)
0x71
switch_CH1
I2C switch (72)
0x72
switch_CH2
I2C switch (73)
0x73
switch_CH3
I2C switch (74)
0x74
switch_CH4
I2C switch (75)
0x75
switch_CH5
I2C switch (76)
0x76
switch_CH6
N/A
N/A
switch_CH7
N/A
N/A
I2C 1
I2C switch (71)
switch_CH0
SFP28 PORT 2
0x50, 0x51
switch_CH1
SFP28 PORT 1
0x50, 0x51
switch_CH2
SFP28 PORT 4
0x50, 0x51
switch_CH3
SFP28 PORT 3
0x50, 0x51
switch_CH4
SFP28 PORT 6
0x50, 0x51
