Configuring the Switch
3-50
3
Private Traps
swPowerStatus
ChangeTrap
1.3.6.1.4.1.259.6.10.64.2.1.0.1 This trap is sent when the power state changes.
swFanFailureTrap 1.3.6.1.4.1.259.6.10.64.2.1.0.17 This trap is sent when the fan fails.
swFanRecoverTrap 1.3.6.1.4.1.259.6.10.64.2.1.0.18 This trap is sent when the fan failure has
recovered.
swIpFilterRejectTrap 1.3.6.1.4.1.259.6.10.64.2.1.0.40 This trap is sent when an incorrect IP address is
rejected by the IP Filter.
swSmtpConnFailure
Trap
1.3.6.1.4.1.259.6.10.64.2.1.0.41 This trap is triggered if the SMTP system cannot
open a connection to the mail server
successfully.
swMainBoardVer
MismatchNotificaiton
1.3.6.1.4.1.259.6.10.64.2.1.0.56 This trap is sent when the slave board version is
mismatched with the master board version. This
trap binds two objects, the first object indicates
the master version, whereas the second
represents the slave version.
swModuleVer
MismatchNotificaiton
1.3.6.1.4.1.259.6.10.64.2.1.0.57 This trap is sent when the slide-in module
version is mismatched with the main board
version.
swThermalRising
Notification
1.3.6.1.4.1.259.6.10.64.2.1.0.58 This trap is sent when the temperature exceeds
the switchThermalActionRisingThreshold.
swThermalFalling
Notification
1.3.6.1.4.1.259.6.10.64.2.1.0.59 This trap is sent when the temperature falls below
the switchThermalActionFallingThreshold.
swModuleInsertion
Notificaiton
1.3.6.1.4.1.259.6.10.64.2.1.0.60 This trap is sent when a module is inserted.
swModuleRemoval
Notificaiton
1.3.6.1.4.1.259.6.10.64.2.1.0.61 This trap is sent when a module is removed.
* These are legacy notifications and therefore must be enabled in conjunction with the corresponding traps on the
SNMP Configuration menu (page 3-42).
Table 3-5 Supported Notification Messages (Continued)
Object Label Object ID Description
